Bidirectional Energy Storage DC/DC Inverter with Ultra-Wide MPPT Range 30Vdc-80Vdc and Pure Sine Wave Output
80 Sold
|
Inquiry
Collected In Wish List
Bidirectional Energy Storage DC/DC Inverter with Ultra-Wide MPPT Range 30Vdc-80Vdc and Pure Sine Wave Output
SKU: 20260624173546C2
$191.5
$191.5
$211.5
$ 22
to
United States
Via
Fedex IP
You May Also Like
-10%
Bidirectional Energy Storage Solar Inverter with Ultra-Wide MPPT Range and Pure Sine Wave Output
$184.52
- $244.52
$204.52
-11%
Ultra-wide MPPT Range 30Vdc-80Vdc Bidirectional Energy Storage Solar Inverter with Pure Sine Wave Output
$165.69
- $225.69
$185.69
-13%
High-Efficiency Off-Grid Solar Inverter with Bidirectional Energy Storage and Ultra-Wide MPPT Range
$131.72
- $191.72
$151.72
Description
Specification
Questions & Answers (0)
Reviews (0)
Efficient Energy Storage Inverter with Smart 230V Control
Dependable Wall-Mounted Home Battery Storage System
High-frequency, high power density compact design delivering exceptional efficiency. Features bidirectional energy storage enabling both solar and mains charging with ultra-wide MPPT range of 30Vdc-80Vdc.
Technical Specifications
| Specification | 1000W | 1300W | 1800W | 1800w | 2300W | 3300W |
|---|---|---|---|---|---|---|
| Rated Power | 1000W | 1300W | 1800W | 1800w | 2300W | 3300W |
| Max PV Input Power | 1500W | 2000W | 2500W | 2500W | 3000W | 5000W |
| MPPT Tracking Voltage Range | 30Vdc-240Vdc | 40Vdc-350Vdc | 40Vdc-450Vdc | |||
| Rated Voltage | 180Vdc | 240Vdc | ||||
| Max PV Input Voltage (VOC) | 300Vdc | 400Vdc | 500Vdc | |||
| Max PV Input Current | 13A | 15A | 18A | - | - | - |
| MPPT Tracking Channels | 1 Routed | |||||
| Battery Type | Lead-acid Battery/Lithium Battery | |||||
| Rated Battery Voltage | 12Vdc | 24Vdc | ||||
| Battery Voltage Range | 10.5-15Vdc (default) | 21-30Vdc (default) | ||||
| Max PV Charging Current | 60A | 80A | 100A | 60A | 80A | 120A |
| Max AC Charging Current | 40A | 50A | 65A | 35A | 50A | 80A |
| Max Charging Current | 60A | 80A | 100A | 60A | 80A | 120A |
| Rated Input Voltage | 230V (220V or 240V can be set) | |||||
| Mains Input Voltage Range | 165Vac-280Vac/120Vac-280Vac (can be set) | |||||
| Rated Input Frequency | 50Hz/60Hz | |||||
| Input Frequency Range | 45Hz-55Hz (50Hz), 55Hz-65Hz (60Hz) | |||||
| Rated Output Voltage | 230V (220V or 240V can be set) | |||||
| Output Voltage Accuracy | ±2% | |||||
| Output Frequency Accuracy | ±1% | |||||
| Output Wave | Pure Sine Wave | |||||
| Grid Voltage Range | 187Vac-264Vac | |||||
| Rated Output Current | 4.3A | 5.6A | 7.8A | 7.8A | 10A | 14.3A |
| Power Factor | >0.98 (Rated Power) | |||||
| No Load Loss | 1% Rated Power (Typical value) | |||||
| MPPT Tracking Efficiency | ≥99.9% | |||||
| Transfer Time | 10ms (Typical value) | |||||
| Display | LCD+LED | |||||
| Cooling Method | Cooling fan in intelligent control | |||||
| Communication | RS485/Mobile APP (WIFI Monitoring or GPRS monitoring) (Optional) | |||||
| Protection Degree | IP20 | |||||
| Anti-islanding Protection | ≤2S | |||||
| Product Size (L·W·H mm) | 265*231*91 | 285*250*91 | 310*250*91 | 285*250*91 | 325*275*102 | - |
| Package Size (L·W·H mm) | 340*286*156 | 360*305*156 | 385*305*156 | 360*305*156 | 400*330*167 | - |
| N.W. (kg) | 3 | 3.6 | 4 | 3.7 | 3.9 | 5.5 |
| G.W. (kg) | 3.5 | 4.5 | 5 | 4.6 | 4.8 | 6.5 |
Advanced Operating Features
Configurable modes: grid-connected, off-grid, hybrid with grid-connected current setting
Output and charging priority settings with BMS communication for lithium batteries
Supports battery-free mode operation
Battery Customization
Customized batteries can be configured with different types of charge and discharge parameters through the operation panel.
Frequently Asked Questions
Why choose us?
Years of expertise, professional sales & R&D team, quality products, competitive pricing, timely delivery, genuine service
How is your after-sale service?
1-2 years warranty, 1% spare parts free, PCB repair or replacement
What certifications do you have?
ISO9001, ISO14001, CE, ROHS, UL, etc. All products pass tests per countries" requirements.
Delivery time:
Standard products delivered within 15 days
Can I have a sample order?
Yes, sample orders are welcome to test quality
Made of high-quality materials with stable performance and safe usage.
Precise craftsmanship ensures excellent texture and stylish appearance.
Ergonomic design brings comfortable experience and easy operation.
Durable structure with long service life and low wear.
Strict quality control guarantees reliable overall quality.
Versatile and practical, suitable for daily, business and gifting scenarios.
Premium QualityFine CraftsmanshipWide ApplicationCost Effective
Focus on details and user experience, providing stable and trustworthy quality.
